Automatic Changeover Switch

  • Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply
  • Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply
  • Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply
  • Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply
  • Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply
  • Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply
Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply

Automatic Transfer Switch ATS WCQ2A Intelligent Double Power Supply

Key Information

WCQ2A

Pole: 3P, 4P

Voltage: AC400V

Icm:7.65KA-52.5KA

Inm(A): 63, 100, 225, 400, 630, 800, 1250

Amps: 10-1250

General

WCQ2 series double power supplies automatic transfer switch (ATS) applies to AC50Hz, rated operation voltage 400V, rated operation current 16A to 2000A, to two circuits power supply of emergency power supply system. It can be set as manual of the mutual transfer between frequent-use and backup power supply, as circuit controlling switch of control, signal, and interlock functions. Some types of the product have communication ports to make it realisable of remote control and unattended substation to the user. It applies to residence community, military facility, hospital, mall, airport, etc.,

The ATS meets standards IEC/EN60947 and GB/T14048.11.


Main technical parameters

Specification Model of circuit breakerFrame size current (A)Rated operation current (A)Breaking current (kA)Rated service voltage (V)Insulation voltage (V)Frequency (Hz)Transfer timeRated operation voltage of controller (V)Mechanical life
WCQ2A(1)-63/3WCM1 series636, 10, 20, 25, 32, 40, 50, 63Take specific type of circuit breaker specification for reference400No flash, no spark-over within 1min 2500V50~600-30 seconds adjustableAC230V5000 times
WCQ2A(1)-63/4
WCQ2A(1)-100/310010, 20, 25, 32, 40, 50, 63, 80, 100
WCQ2A(1)-100/4
WCQ2A(1)-225/3225100, 125, 140, 160, 180, 200, 225
WCQ2A(1)-225/4
WCQ2A(1)-400/3400200, 250, 315, 400
WCQ2A(1)-400/4
WCQ2A(1)-630/3630250, 315, 400, 500, 630
WCQ2A(1)-630/4
WCQ2A(1)-800/3800630, 700, 800
WCQ2A(1)-800/4
WCQ2A(1)-1250/320001250, 1600, 2000
WCQ2A(1)-2000/3
